BI+10G-1213-60K-D (I)
BI+10G-1312-60K-D (I)
10Gb/s BIDI SFP+ 60km Transceiver
Previous
Next
Product Description
BI+10G-1213-60K-D(I) is hot pluggable 3.3V Small-Form-Factor transceiver module. It designed expressly for high-speed communication applications that require rates up to 11.3Gb/s, it designed to be compliant with SFF-8472 SFP+ MSA. The module data link up to 60km in 9/125um single mode fibre.
Product Features
- Up to 11.3Gbps Data Links
- Up to 60km transmission on SMF
- Power dissipation<1.5W
- 1270nm DFB laser and PIN receiver for BI+10G-1213-60K-D(I)
- 1330nm DFB laser and PIN receiver for BI+10G-1312-60K-D(I)
- 2-wire interface with integrated Digital Diagnostic monitoring
- EEPROM with Serial ID Functionality
- Compliant with SFP+ MSA with LC connector
- Single + 3.3V Power Supply
- Case operating temperature:
- Commercial: 0°C to +70°C
- Industrial: -40°C to +85°C
Applications
- 10GBASE-BX
- 10G SONET/SDH, OTU2/2e
Standard
- Compliant with SFF-8472
- Compliant to SFF-8431
- RoHS Compliant
Ordering Information
Product Part Number
Data Rate (Gbps)
Media
Wavelength (nm)
Transmission Distance (m)
Temperature Range (Tcase) (°C)
BI+ 10G-1213-60K-D
10.3125
Single mode fibre
1270/1330
60
-5~70
Commercial
BI+ 10G-1213-60K-D
10.3125
Single mode fibre
1330/1270
60
-5~70
Commercial
BI+ 10G-1213-60K-DI
10.3125
Single mode fibre
1270/1330
60
-40~85
Industrial
BI+ 10G-1213-60K-DI
10.3125
Single mode fibre
1330/1270
60
-40~85
Industrial
